Eaton EASY-E4 Series User Manual

11. Connection to other devices
11.3 Setting up a NET
Enable all the NET stations for which you want the new program to be loaded.
Confirm your selection with OK.
The programs for all the selected NET stations will be loaded onto the devices.
Project view
Figure 255: NET tab for the selected base device in the NET group
NET group
Used to select the group for the selected base device.
0 Base device running in standalone mode with the relevant I/O expan-
sions (if any),
no NET group
1-10 Available NET group numbers
NET-ID
Used to assign a group device number to the selected base device.
0 Base device running in standalone mode with the relevant I/O expan-
sions (if any)
1-8 Available device IDs in the NET group
542
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
