Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
The year time switch HY01 is required to switch on at 00:00 on day 1 of each month and
switch off at 00:00 on day 29 of each month.
The HY year time switch must be assigned the following parameters:
Programming view/HY01/Year time switch parameters tab
Figure 109: Figure: Entry screen in the programming software
Example 4: Select “public holidays"
The year time switch HY01 is required to switch on at 00:00 on day 5.12 of each year
and switch off at 00:00 on day 28.12 of each year.
The HY year time switch must be assigned the following parameters:
Programming view/HY01/Year time switch parameters tab
Figure 110: Figure: Entry screen in the programming software
easyE4 11/18 MN050009 EN www.eaton.com
185

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
