Eaton EASY-E4 Series User Manual

2. Installation
2.5 External connections
Remove microSD
Pull out the slot.
Push the microSD card into the slot.
The memory card will be released and come out a bit
Remove the memory card.
Store the microSD in its case in order to protect it.
Close the slot
Figure 27: Removing the memory card
easyE4 11/18 MN050009 EN www.eaton.com
63

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
