Eaton EASY-E4 Series User Manual

3. Commissioning
3.3 Switch on
3.3.2 Startup behavior of easyE4 control relays with a display and keypad
If there is no program, the control relay will start in STOP mode.
All the information on the display will be shown in English if the device is configured
with its factory settings.
If there is an executable program on the easyE4 control relays, the device will start in
RUN mode.
In addition to having a valid program on the control relay,
please make sure that there are no peripheral faults that will
lead to STOP mode.
easyE4 base device with integrated display
l If there is no splash screen on the memory card
after being switched on, the easyE4 base device will show
the Eaton logo and then the status display. This status dis-
play provides information on the device's status.
l If there is a splash screen on the memory card
after being switched on, the easyE4 device will show the
splash screen and then the status display. This status dis-
play provides information on the device's status.
If there is no executable program on the easyE4 control relays, the device will start in
STOP mode.
All the information on the display will be shown in English if the device is configured
with its factory settings. Once the device is ready for operation, the status display will
appear.
I 1 . . 4 . 7 8 . .
N T 1 P
MO 1 3 : 0 8
Q 1 . . 4 R U N
M A C : 0 0 2 2 C 7 1 2 3 4 3 E
1 6 7 . 6 7 . 3 . 1
Figure 46: Example of status display on display
78
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
