Eaton EASY-E4 Series User Manual

Appendix
A.3 Technical data
A.3 Technical data
A.3.1 Data sheets
The current specifications for the device can be found in the corresponding data sheet
at www.eaton.eu/ecat
A.3.1.1 Base devices
with display and buttons with LED indicators for diagnostics
197211 - EASY-E4-UC-12RC1 197212 - EASY-E4-UC-12RCX1
197213 - EASY-E4-DC-12TC1 197214 - EASY-E4-DC-12TCX1
A.3.1.2 Expansions
with relay outputs with transistor outputs
197217 - EASY-E4-UC-8RE1 197219 - EASY-E4-DC-8TE1
197218 - EASY-E4-UC-16RE1 197220 - EASY-E4-DC-16TE1
with analog inputs
197223 - EASY-E4-DC-6AE1
A.3.1.3 Accessory devices
197225 - EASY-E4-CONNECT1
Spare parts package,
consisting of three (3) connectors and three (3) end covers
197226 - EASYSOFT-SWLIC
Programming software license easySoft 7
191087 - MEMORY-SDU-A1
microSD memory card
584
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
