Eaton EASY-E4 Series User Manual

Table of Contents
easyE4 Manual 1
Imprint 2
Before starting with the installation 3
Table of Contents 1
0.1 About this manual 13
0.1.1 List of revisions 13
0.1.2 Target group 13
0.1.3 Legal disclaimer 14
0.1.4 Short designations 15
0.1.5 Writing conventions 16
0.1.5.1 Warning labels 16
0.1.5.2 Documents with additional information 17
1. easyE4 control relays description 19
1.1 Use as intended 19
1.2 Function 19
1.2.1 Features 20
1.3 Device models - versions and part nos. 21
1.3.1 Basic features 21
1.3.2 Base device versions 22
1.3.3 I/O expansion versions EASY-E4-...-...E1 23
1.4 Accessory devices 24
1.5 What the different parts of the part number mean 25
1.6 Nameplate 25
1.7 Support 26
1.8 Overview of devices 27
1.9 Programming software easySoft 7 28
1.10 Safety regulations 29
1.10.1 Basics 29
1.10.2 Mandatory requirements, personnel requirements 29
1.10.2.1 Occupational safety 29
1.10.2.2 Personnel qualifications 29
easyE4 11/18 MN050009 EN www.eaton.com
1

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
