4. Operation
4.5 Your first EDP program
Press the OK button twice,
to move the cursor across the 001 to the second contact field.
You could also move the cursor to the next contact field using the cursor button.
Press the OK button.
The easyE4 device will once again insert an I001 contact at the cursor position.
Press the OK. button so that the cursor will jump to the next position.
Use the or cursor buttons to select the number 002.
Pressing DEL will delete the contact at the cursor position.
Press the OK button to move the cursor to the third contact field.
You do not need a third relay contact, so you can now wire the contacts directly up to
the coil field.
Wiring
easyE4 device displays a small arrow in the circuit diagram when creating the wir-
ing.
Press the ALT button to activate the arrow and press the cursor buttons
to move it. Pressing the ALT button once more switches the cursor back to Move
mode.
The ALT button also has two other functions depending on the cursor pos-
ition:
l In the left contact field, you can press the ALT button to insert a new
empty circuit connection.
l The contact under the cursor can be changed between a N/O and N/C
contact by pressing the ALT button.
The wiring arrow works between contacts and relays.
When you move the arrow onto a contact or relay coil, it changes back to the cursor
and can be reactivated if required.
The easyE4 device automatically connects adjacent contacts up to the
coil.
Press the ALT to wire the cursor from I002 through to the coil field.
The cursor changes into a flashing wiring arrow and automatically jumps to the next
logical wiring position.
Press the cursor button .
Contact I002 will be connected up to the coil field.
108
easyE4 11/18 MN050009 EN www.eaton.com
