Eaton EASY-E4 Series User Manual

5. Programming on the device
5.2 Circuit diagram display
Program display on the display
l Connections are used to produce the electrical contact between relay contacts and
the coils. They can be created across several rungs. Each point of intersection is a
connection.
l The number of free bytes is displayed so that you can recognize how much memory
is available for the circuit diagram and function blocks.
The circuit diagram display has two functions:
l It is used to edit the circuit diagram in STOP mode.
l It is used in RUN mode to check the circuit diagram using
the power flow display.
easyE4 11/18 MN050009 EN www.eaton.com
123

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
