Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Device parameter Control mode easySoft 7 Note
X
â
On/off delayed There are two time setpoints to be
configured.
?X
#
On/off-delayed with random time With random time, 2 time setpoints
ü
Single pulse Normalizes input signals of dif-
ferent pulse lengths to a fixed pulse
length at the switch contact of the
timing relay.
Ü
Flashing
Time values:
S1=Pulse time,
S2= Pause time;
Time values
Two time reference values need to
be configured.
I1=Pulse time,
I2= Pause time;
Synchronous flashing: I1 = I2
Mark-to-space ratio = 1:1
Asynchronous flashing: I1 ≠ I2
Mark-to-space ratio ≠ 1:1
#
Off-delayed with retriggering Retriggerable reference value
?
#
Off-delayed with retriggering and
random time
Retriggerable reference value
Function block outputs
Description Note
(Bit)
Q1 Switching contact
(DWord)
QV Elapsed actual time in RUN mode Integer value range:
0 to max. 99990 in time range: seconds;
milliseconds; hours
depending on configured time range.
Parameter set
Configuration/time range Description Note
S Seconds:Milliseconds
Configurable as a constant:
00.005 to 999.995 (s.ms)
Resolution: 5 ms
M : S Minutes:Seconds
Configurable as a constant:
00:01 to 99:59 (min:s)
Resolution: 1 s
H : M Hours:Minutes
Configurable as a constant:
00:01 to 99:59 (h:min)
Resolution: 1 min
Parameter display
+ Call enabled
Function block parameters and con-
stants can be edited on the device.
Simulation possible
198
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
