Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Operands Value inputs
NB, NW, ND - NET markers x
nNB, nND, nND- NET markers
NET stations n
x
IA - Analog input x
QA - Analog output x
QV - QV - Numeric output of a FB x
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1 x
M – Markers x
RN - Input bit via NET x
SN - Output bit via NET (send) x
N - Net marker bit x
nN - NET marker bit NET station n x
ID: Diagnostic alarm x
LE - Output backlight x
P buttons x
I - Bit input x
Q - Bit output x
Q - Bit output of a FB x
Function block outputs
Description Note
(Bit)
OF Overflow
1: if QV ≥ SH
OF=1, if the actual value is
greater than or equal to the
upper threshold value;
FB Fall below
1: if QV ≤ SL
FB=1, if the actual value is less
than or equal to the lower
threshold value;
CY Carry
1: if QV > value range
If the value range is exceeded,
the switch contact switches to
status 1 for one cycle per rising
edge detected. The function
block retains the value of the
last valid operation before the
contact CY is set.
ZE Zero
1: if QV = 0
(DWord)
QV Current counter value in RUN mode The pulses at channel A and
channel B are counted. 2 pulses
are counted per counting
period.
Example: 2 pulses at channel A
easyE4 11/18 MN050009 EN www.eaton.com
239

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
