Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Operands Bit inputs
RN - Input bit via NET
SN _ Output bit via NET (send)
N - Network marker bit
nN - NET station n marker
ID: Diagnostic alarm
LE - Output backlight
x
x
x
x
x
x
I bit input x
Q Bit output from another FB x
Function block outputs
Description
(Bit)
Q1 Switch output 1
Q2 Switch output 2
Assigning operands
You can assign the following operands to the function block outputs that are bit outputs:
Operands Bit outputs
Q1, Q2
Constant 0, constant 1 x
M – Markers
RN - Input bit via NET
SN _ Output bit via NET (send)
N - Network marker bit
nN
ID: Diagnostic alarm
LE - display brightness indicators
x
x
x
x
x
x
x
I bit input x
Q Bit output from another FB x
easyE4 11/18 MN050009 EN www.eaton.com
299

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
