Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
BC11E1o
BC11E2s
BC11E3j-----------------------Ä M 48
BC11EQ-BC11EN-----------------Ä M 49
Figure 162: Wiring the contacts
Example of an AR configuration on a device display
When using the function block in the circuit diagram for the first time, use OK to auto-
matically enter the display of function blocks on the device display, as shown in the fol-
lowing figure.
BC11 +
>I1
>I2
> NO
Figure 163: Parameters on the display
Enter the function block settings here. The display contains the following elements:
BC11 block
compare
Function block: Data block comparator, number 11
+ Parameter set can be called via the PARAMETERS menu
>I1 Start of comparison range 1; the data block with the start address present at
input I1 is compared with the data block with the start address present at
input I2.
>I2 Start of comparison range 2
> NO Number of elements to be compared in bytes per range, number: 1 - 383
See also
→ Section "BC - Block compare", page 306
→ Section "FT - PT1-Signal smoothing filter ", page 279
→ Section "TC - Three step controller", page 297
→ Section "VC - Value limitation ", page 302
→ Section "BV - Boolean operation", page 353
→ Section "PO - Pulse output", page 284
310
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
