Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Function block outputs
Description Note
(Bit)
RY Ready
0: Logging is enabled (in the case of ring buf-
fers, RY = 0 always)
1: Logging inactive
Logging can be disabled because:
l n log files have been written
l The memory card is full
l No memory card inserted
l Memory card faulty
BY Busy
1: Logging not possible
Possible causes:
l The card is currently being written to
l The temporary internal buffer is full
E1 Error output
1: Data loss
Possible causes:
l No memory card inserted
l The memory card does not have
enough space for another log file
l Memory card faulty
l Temporary internal buffer overflow
by at least one record
Assigning operands
You can assign the following operands to the function block outputs that are numeric
outputs:
Assigning operands Outputs
Constant x
Markers: MB, MD, MW x
Analog inputs IA x
Analog output QA x
Numeric output from another QV FB x
You can assign the following operands to the function block outputs that are bit outputs:
Assigning operands Bit outputs
Constant 0, constant 1 x
M – Markers x
SN - Output bit via NET (send) x
N - Network marker bit x
nN - NET station n marker x
LE - Output backlight x
Q - Bit output from another FB x
382
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
