Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Enter the function block settings here. The display contains the following elements:
MR16 master
reset
Function block: Master reset, number 16
Q Operating mode: Reset outputs
+ Parameter set can be called via the PARAMETERS
menu
See also
→ Section "AL - Alarm function block", page 349
→ Section "BV - Boolean operation", page 353
→ Section "D - Text display", page 357
→ Section "D - Text display editor", page 366
→ Section "DL - Data logger", page 380
→ Section "JC - Conditional jump", page 386
→ Section "LB - Jump label", page 391
→ Section "NC - Numerical converter", page 397
→ Section "ST - SET cycle time", page 403
396
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
