Eaton EASY-E4 Series User Manual

6. Function blocks
6.1 Manufacturer function blocks
However, since a BCD source cannot five a negative number at I1, a negative numeric
conversion at QV is simply a theoretical case.
Values greater than 161061273 are output as 9999999.
Values less than –161061273 are output as –9999999.
The working range of the function block has been exceeded.
Example of a numerical converter function block when using the EDP programming
language
Function block input NC..EN is connected directly to device terminal I5
I 05-----------------------------Ä NC01EN
Figure 185: Wiring the function block coils
NC02 BCD +
>I1
QV>
Figure 186: Parameter configuration on the device
See also
→ Section "AL - Alarm function block", page 349
→ Section "BV - Boolean operation", page 353
→ Section "D - Text display", page 357
→ Section "D - Text display editor", page 366
→ Section "DL - Data logger", page 380
→ Section "JC - Conditional jump", page 386
→ Section "LB - Jump label", page 391
→ Section "MR - Master reset", page 393
→ Section "ST - SET cycle time", page 403
402
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
