Eaton EASY-E4 Series User Manual

11. Connection to other devices
11.4 Modbus TCP
Function code
Modbus
Modbus
reg.#
Operand Description Remark
0x06
(Write Single
Register)
and
0x10
(Write Multiple
Register)
1001 MW1 Marker word 1
… … …
1512 MW512 Marker word 512
2001 NW1 NET marker
word 1
… … …
2032 NW32 NET marker
word 32
Table 106: How the Modbus registers and write data for the easyE4 Modbus server are mapped
Please note that little-endian is used when converting bytes to words in
an easyE4. If you want to implement Modbus communications with big-
endian, you will need to make the necessary adjustments.
See also
easySoft 7 Help
easyE4 11/18 MN050009 EN www.eaton.com
559

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
