Eaton EASY-E4 Series User Manual

11. Connection to other devices
11.5 Setting up a web server
Enter a web server login text into the corresponding text field.
Please note than changing the web server login text for the device will require you to
set up the passwords again.
Clicking on OK or Cancel will take you back to the Webserver configuration section.
Now select whether you want the web server to be Always enabled
or
if Activation by program should instead be required.
One reason you may want to consider having a specific program enable the web server
is for added protection.
80 will be set as the default "HTTP port".
If you change this port, please make sure that the HTTP port is set to the same value
both on the web browser and on the easyE4 device.
Set the HTTP port you want.
Enable SSL/TLS encryption if necessary.
Now define the ranges that can be written to via the web server with the From and To
drop-down menus.
Select the range for Enable marker (write)
Select the range for Enable NET marker (write)
easyE4 11/18 MN050009 EN www.eaton.com
561

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
