Eaton EASY-E4 Series User Manual

4.3.2 Operating principle in the circuit diagram and function block
editor 93
4.3.3 Selecting a device menu 94
4.4 Overview of the menus on the device 95
4.4.1 Main menu 95
4.4.2 STOP RUN operating mode menu 95
4.4.3 Menu Parameter 96
4.4.4 Set clock menu 97
4.4.5 Menu Card 98
4.4.6 Menu Information 99
4.4.7 System options menu 100
4.4.8 Program menu 102
4.5 Your first EDP program 104
4.5.1 Draw a wiring diagram 106
4.5.2 Testing the circuit diagram 110
4.5.3 Control options in RUN mode 111
4.5.4 Delete program 113
4.6 Transfer program to the easyE4 device 114
4.6.1 Transfer with a microSD memory card 114
4.6.2 Establish Ethernet connection 119
5. Programming on the device 121
5.1 Program 121
5.2 Circuit diagram display 122
5.3 Circuit diagram elements 124
5.3.1 Function blocks 124
5.3.2 Relays 124
5.3.3 Contacts 125
5.3.4 Coils 126
5.3.5 Markers and analog operands 131
5.4 Working with contacts and coils 133
5.4.1 Entering and modifying contacts 134
5.4.2 Changing an N/O contact to an N/C contact 135
5.4.3 Entering and modifying coils 136
5.4.4 Deleting contacts and coils 137
4
easyE4 11/18 MN050009 EN www.eaton.com

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
