3. Commissioning
3.6 Automatic booting of the memory card
3.6.1 Preparing the card in the device for booting with easySoft 8
Only possible with easySoft 8.
Prerequisites
l
Licensed easySoft 8 version on the PC
Insert the microSD memory card into a card reader on your PC.
Open easySoft 8 and open the project you want to transfer, e.g., <test.e80>.
If you want the starting program on the card to overwrite the current program
on the device again later on, make sure to enable the Allow overwriting via card
option in Project view/System settings tab.
Start setting up the card by clicking on the Project/Card... menu option.
If this is the first time you click on this menu option, make sure to select the
drive corresponding to the microSD card.
The Card setup dialog box will appear.
easyE402/24 MN050009ENEaton.com
125
