This section is intended to guide you step-by-step through the process of creating
your first program with the easy Device Programming (EDP) language in order to wire
a circuit diagram. This should enable you to become familiar with all the relevant
rules and use an easyE4 device for your own projects in no time. Just like with con-
ventional wiring, you will be using contacts and relays in the program. This means
that the easyE4 device makes it possible to eliminate the use of these components in
a variety of ways, including the use of function blocks.
The easyE4 program will take care of the entire wiring for these components.
All you have to do is then connect to the easyE4 any switches, sensors, lamps or con-
tactors you wish to use.
Use easySoft 8 to create your own program
 Opens another menu
STOP ✓ RUN
PARAMETERS
SET CLOCK
CARD
INFORMATION
SYSTEM OPTIONS
PROGRAM
Tab. 62: Main menu
CIRCUIT DIAGRAM
FUNCTION BLOCKS
Tab. 63: Programs

Prerequisites for entering a circuit diagram
l
The easyE4 device is in STOP operating
mode.
l
The display must be showing the status dis-
play.
Press the OK button to get to the main menu from the status display.
Use the buttons to scroll to the Programs menu option.
Open the menu option by pressing the OK button.
The PROGRAMS\CIRCUIT DIAGRAM menu option will now be selected on the easyE4
device.
In general, press the OK button to switch to the next menu level, and press the ESC
button to move one level back.
Press the OK button twice to enter the circuit diagram display via menu options
<PROGRAM… ->CIRCUIT DIAGRAM>. This is where you will create the circuit
diagram.
