2. Installation
2.1 Prerequisites for the location of use
l
Do not touch system components or cables without a ground wire (if there was
one previously) anymore
l
Reinstall all safety covers, safety enclosures, safety labels, and safety signs
l
Do not remove safety measures at switching points until you get the all-clear for
the areas where work was performed
l
If carrying out work that involves more than one worker, make absolutely sure
that nobody is still in the danger zone
2.1 Prerequisites for the location of use
The device must be used exclusively in locations for which it has been approved/cer-
tified.
The supply voltage must be guaranteed and must conform to the relevant spe-
cifications-
 Nameplate → page 35 and
the specifications in the → Section "Technical data", page 825 for the individual
devices → page 825
CAUTION
INSTALLATION CUT-OUT
The mounting cutout must be located in a position that will not defeat
the purpose of stabilizing webs or other reinforcing elements in the
control panel. If necessary, reinforcing elements must be installed/ad-
ded.
2.1.1 Installation position
easyE4 devices are intended to be flush mounted in control cabinets, control panels,
service distribution boards, or control consoles from behind.
The following must be taken into account when selecting the installation position:
l
The controls and connectors must remain accessible even after the device has
been installed.
l
easyE4 devices can be installed in a horizontal or vertical position.
The slot for the microSD memory card is located under a cover on
the base device.
Please observe the clearance required in order to be able to
remove the microSD and use the buttons.
54
easyE402/24 MN050009ENEaton.com
