3. Commissioning
3.6 Automatic booting of the memory card
The “File selection” window opens.
If the list does not show any files, this means that there are no programs on the
card.
Enter the name you want for the program into the drop-down menu, e.g., <test>.
This name can be different from the *.e80 file's name. You can also select a
name from the menu.
Confirm your selection with OK. This will transfer the program for the device
selected in the Project view to the card.
If the project is a NET application, the "Selection of NET station" dialog box will
appear.
Select the NET station with the program that you want to transfer to the
microSD memory card, e.g., <NET station NT1>.
A plausibility check is then run. If the plausibility check is completed successfully,
the prompt will appear after the start program.
easyE402/24 MN050009ENEaton.com
127
