Eaton easyE4 User Manual

6. Function blocks
6.1 Manufacturer function blocks
Function block outputs
 Description Note
(bit) 
Q1
1: During the time between sunrise and sun-
set

E1
Error
1: If the device location's latitude exceeds the
value range – please refer to Project view/C-
lock tab

or if O1, O2 exceeds the value range.
Integer value range starting from the
prime meridian:

Longitude
-180…+180 (W…O)

Latitude
-89.899…+89.899 (S…N)
(-89°54'…+89°54')
(DWord)


T1
Hours in the switch-on time calculated on the
basis of the calculated sunrise and the value
at O1
Integer value range:
0…23
T2
Minutes in the switch-on time calculated on
the basis of the calculated sunrise and the
value at O1
Integer value range:
0…59
T3
Hours in the switch-off time calculated on the
basis of the calculated sunset and the value at
O2
Integer value range:
0…23
T4
Minutes in the switch-off time calculated on
the basis of the calculated sunset and the
value at O2
Integer value range:
0…59
Assigning operands
You can assign the following operands to the function block outputs that are numeric
outputs:
Assigning operands Value outputs
MB, MD, MW – Markers
x
NB, NW, ND – NET markers
2)
NET station n
x
QA – Analog output
x
I – Value input of a FB
x
2)
Only on projects with ≥ 2 base devices on NET 
You can assign the following operands to the function block outputs that are bit out-
puts:
Assigning operands Bit outputs
M - Markers
x
SN – Output bit via NET (send)
2)
SN - Output
bit via NET (send)
x
N – Network marker bit
2)
x
LE – Output backlight
x
easyE402/24 MN050009ENEaton.com
297
