6. Function blocks
6.1 Manufacturer function blocks
The function block and its parameters
Function block inputs
 Description Note
(bit) 
EN
1: Activates the function block.
The checkbox for the
Function block release by EN is neces-
sary
parameter must first be enabled
C_
Counter input, counts with every rising edge

D_
Count direction
0: up counting
1: down counting

SE
The starting value at SV is applied whenever
there is a rising edge at this input

RE
Reset
1: QV=0
Reset the counter to zero
(DWord) 
SH
Counter relay
Integer value range:
-2,147,483,648 to +2,147,483,647
SL
Lower threshold value
SV
Start value (Pre Set)
When there is a rising edge at SE, this
value will be applied as the counter value.
Integer value range:
-2,147,483,648 to +2,147,483,647
Assigning operands
You can assign the following operands to the function block inputs that are numeric
inputs.
Operands Value inputs
Constant, timer constant
1)
x
MD, MW, MB - Markers
x
NB, NW, ND - NET markers
2)
x
nNB, nND, nND- NET markers
2)
NET station n
x
IA - Analog input
x
QA - Analog output
x
QV - QV - Numeric output of a FB
x
1)
Only on function blocks T, AC
2)
Only on projects with ≥ 2 base devices on NET
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1
x
M - Markers
x
RN - Input bit via NET
2)
x
SN - Output bit via NET (send)
2)
x
easyE402/24 MN050009ENEaton.com
305
