6. Function blocks
6.1 Manufacturer function blocks
Example of a CP configuration on a device display
When using the function block in the circuit diagram for the first time, use OK to auto-
matically enter the display of function blocks on the device display, as shown in the
following figure.
CP12 +
>I1
>I2
Fig. 183: Parameters on the display
Enter the function block settings here. The display contains the following elements:
 
CP12 comparator
Function block: Value comparator, number 12
+
Parameter set can be called via the PARAMETERS menu
>I1
Reference value to which the comparison is made
Integer value range:
-2,147,483,648 to +2,147,483,647
>I2
Comparison value; I2 is compared with I1
Integer value range:
-2,147,483,648 to +2,147,483,647
See also
 → Section "A - Analog value comparator", page 329
 → Section "AR - Arithmetic", page 335
 → Section "AV - Average", page 340
 → Section "LS - Value scaling", page 353
 → Section "MM - Min-/Max function", page 358
 → Section "PM - Performance map ", page 361
 → Section "PW - Pulse width modulation", page 367
352
easyE402/24 MN050009ENEaton.com
