6. Function blocks
6.1 Manufacturer function blocks
Other
Retention
The function block does not recognize retentive data.
Example of an FT-PT1-signal smoothing filter when using the EDP programming
language

M 40-----------------------------Ä FT01EN
Fig. 195: Wiring the function block coils
Example of an FT-PT1 signal smoothing filter configuration on a device display
When using the function block in the circuit diagram for the first time, use OK to auto-
matically enter the general display of function block parameters, as shown in the fig-
ure on the left. Enter the function block settings here.
FT17 +
>I1
>TG
>KP
QV>
Fig. 196: Parameters shown on display
The display contains the following elements:
 
FT17 signal
smoothing fil-
ter
Function block: Signal smoothing, number 17
+
Parameter set can be called via the PARAMETERS menu
>I1
Input value: -32768… +32767
>T
G
Recovery time: 0… 65535 resolved in 100 ms
Example: The value 250 is processed in the function block as 25 s.
>K
P
Proportional gain: 0… 65535 in %; Example: With KP=1500 the function
block performs the calculation with K
p
=15
QV>
Output value: -32768 … +32767, smoothed
See also
 → Section "BC - Block comparison", page 410
 → Section "BV - Boolean operation", page 470
 → Section "PO - Pulse output", page 386
 → Section "TC - Three step controller", page 401
 → Section "VC - Value limitation ", page 406
easyE402/24 MN050009ENEaton.com
385
