Eaton easyE4 User Manual

6. Function blocks
6.1 Manufacturer function blocks
 Description

Note
0 – +2147483647
FS

Start Frequency  Integer value range:
0…5000 Hz
FO

Operating frequency  Integer value range:
0…5000 Hz
RF
Frequency change in
the acceleration phase
[mHz/step]
 Integer value range:
0…65 535
Value for changing the frequency during the acceleration in 0.001Hz per
step.
Example:
0 = No frequency change
100 = Frequency increased by 0.1 Hz per step
BF
Frequency change in
the braking phase
[mHz/step]
 Integer value range:
0…65 535
Value for changing the frequency during braking in 0.001Hz per step.
Example:
0 = No frequency change
1000 = Frequency reduction by
1 Hz per step
P1
Number of steps in jog
mode
 If you only define a very low number of steps, the start pulse at the TP
function block input must likewise only be very short. Otherwise the func-
tion block will output several pulse sequences that will cause the dis-
tance A to be covered several times. In extreme cases generate short
start pulses at TP using a T... timing relay.
Integer value range:
0…65 535
PF
Jog frequency  Integer value range:
0…5000 Hz
easyE402/24 MN050009ENEaton.com
391
