6. Function blocks
6.1 Manufacturer function blocks
Fig. 210: Parameters on the display
Enter the function block settings here. The display contains the following elements:
BT07 block transfer
Function block: block transfer, number 07
INI
Operating mode: INI - Initialize
+
Parameter set can be called via the PARAMETERS menu
>I1
Start address of source range or initialization markers (MB,MW,MD)
>I2
Start address destination range
> NO
Number of elements to be written in bytes per range, number: 1…383
Example of a block transfer function block when using the EDP programming lan-
guage
The trigger coil is connected to a device input.

I 05-----------------------------Ä BT07T_
Fig. 211: Wiring the trigger coil
BT07E1o
BT07E2s
BT07E3--------------------------Ä M 42
Fig. 212: Wiring the contacts
The messages of the function block are sent as a group message to a marker M42.
See also
 → Section "Organizing marker ranges", page 234
 → Section "Retention function", page 636
 → Section "BC - Block comparison", page 410
 → Section "DB - Data function block", page 424
 → Section "MX - Data multiplexer", page 429
 → Section "SR - Shift register", page 439
 → Section "TB - Table function", page 447
 → Section "RE - Recipe records ", page 433
easyE402/24 MN050009ENEaton.com
423
