Eaton easyE4 User Manual

6. Function blocks
6.1 Manufacturer function blocks
Operands Bit inputs
P device buttons
x
I - Bit input
x
Q - Bit output
x
Q - Bit output of a FB
x
2)
Only on projects with ≥ 2 base devices on NET
Function block outputs
 Description Note
(bit) 
Q1
1: if T_=1;
0: if T_=0 or E1=1 or EN=0;

RY
1: The record for the requested recipe with
number NO has been loaded.
0: No recipes are loaded.
0: The value at NO has changed, but the
record for the recipe has not been loaded and
is not present at D1 through D8.

E1
Error
1: If the recipe with requested number NO
does not exist or the value range of NO is
exceeded.
0: As soon as there is a value at NO with
which the record in a valid recipe can be
addressed.

(DWord)


D1…D8
Values in the record of the recipe selected
with NO.
Integer value range:
-2,147,483,648 to +2,147,483,647
Assigning operands
You can assign the following operands to the function block outputs that are numeric
outputs:
Assigning operands Value outputs
MB, MD, MW – Markers
x
NB, NW, ND – NET markers
2)
NET station n
x
QA – Analog output
x
I – Value input of a FB
x
2)
Only on projects with ≥ 2 base devices on NET 
You can assign the following operands to the function block outputs that are bit out-
puts:
Assigning operands Bit outputs
M - Markers
x
SN – Output bit via NET (send)
2)
SN - Output
bit via NET (send)
x
N – Network marker bit
2)
x
436
easyE402/24 MN050009ENEaton.com
