Eaton easyE4 User Manual

6. Function blocks
6.1 Manufacturer function blocks
Assigning operands
You can assign the following operands to the function block inputs that are numeric
inputs.
Operands Value inputs
Constant, timer constant
1)
x
MD, MW, MB - Markers
x
NB, NW, ND - NET markers
2)
x
nNB, nND, nND- NET markers
2)
NET station n
x
IA - Analog input
x
QA - Analog output
x
QV - QV - Numeric output of a FB
x
1)
Only on function blocks T, AC
2)
Only on projects with ≥ 2 base devices on NET
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1
x
M - Markers
x
RN - Input bit via NET
2)
x
SN - Output bit via NET (send)
2)
x
N - Net marker bit
2)
x
nN - NET marker bit
2)
NET station n
x
ID: Diagnostic alarm
x
LE - Output backlight
x
P device buttons
x
I - Bit input
x
Q - Bit output
x
Q - Bit output of a FB
x
2)
Only on projects with ≥ 2 base devices on NET
Operating mode
BCD mode
The BCD value at I1 will be converted to a binary value and output at output QV. The
binary value is displayed as a decimal value.
BIN mode
The binary value present at input I1 is converted to a BCD value and supplied at the
output QV. The binary value is displayed as a decimal value.

Description Note
BCD
Converts a BCD value to a binary value.

BIN
Converts a binary value to a BCD value.

554
easyE402/24 MN050009ENEaton.com
