6. Function blocks
6.2 Interrupt function blocks
Assigning operands Value outputs
MB, MD, MW – Markers
x
NB, NW, ND – NET markers
2)
NET station n
x
QA – Analog output
x
I – Value input of a FB
x
2)
Only on projects with ≥ 2 base devices on NET 
You can assign the following operands to the function block outputs that are bit out-
puts:
Assigning operands Bit outputs
M - Markers
x
SN – Output bit via NET (send)
2)
SN - Output
bit via NET (send)
x
N – Network marker bit
2)
x
LE – Output backlight
x
Q – Bit output
x
I – Bit input of a FB
x
2)
Only on projects with ≥ 2 base devices on NET 
Parameter set
 Description Note
Function block release by
EN is necessary
If this checkbox is enabled, the
state of function block input EN will
be evaluated. If the checkbox is dis-
abled instead, the function block
will be enabled and function block
input EN will not do anything.
This parameter ensures that
when existing programs are
copied, the functionality of the
function blocks that are carried
over will be retained. The para-
meter will be automatically set to
0 or 1 depending on the function
block.
Parameter display
+ Call enabled
Constants can be edited on the
device, as can function block para-
meters when using the EDP pro-
gramming language.

Edit interrupt routine
Clicking on the button will open the
interrupt routine

Simulation possible


6.2.1.4 Other
Retention
The function block does not recognize retentive data.
The interrupt program does not have any retentive data.
Monitoring the interrupt load
In total, no more than 8 interrupt sources are allowed to be processed in a single pro-
gram. The valid interrupt sources are the IC, IE, IT interrupt function blocks and the
CF, CH, and CI high-speed counters that are directly connected to the device inputs.
