10. easyE4 communication Connection to other devices
10.12 Setting up a NET group
This basic principle applies to all network markers in all data formats.
Network markers overlap in the various data formats:
N1-8
N9-16
N17-
24
N25-
32
N33-
40
N41-48
N49-56
N57-64
NB1
NB2
NB3
NB4
NB5
NB6
NB7
NB8
NW1 NW2 NW3 NW4
ND1 ND2








N65-
72
N73-
80
N81-
88
N89-
96
N97-
104
N105-
112
N113-
120
N121-
128
NB9
NB10
NB11
NB12
NB13
NB14
NB15
NB16
NW5 NW6 NW7 NW8
ND3 ND4
etc.
NET station heartbeat
In order to make it possible for all NET stations within a group to be able to know
whether NET stations important to them are still communicating, each station cyc-
lically sends a heartbeat every second (1 s).
If a heartbeat is not received, the corresponding error bit ID01 – 08 will be set to "1"
until a heartbeat is detected.
