4 Servicing the Network Management Module
4.1 Configuring/Commissioning/Testing LDAP
4.1.1 Commissioning
Refer to the sectionContextual help>>>Settings>>>Local users to get help on the configuration.
4.1.1.1 Configuring connection to LDAP database
This step configures the LDAP client of the network module to request data from an LDAP base.
Activate LDAP.
Define security parameters according to LDAP servers' requirements.
Configure primary server (and optionally a secondary one).
If security configuration needs server certificate verification, import your LDAP server certificate.
Refer to the section to get help on certificate import.
In case LDAP server certificate is self-signed, import the self-signed certificate in the Trusted remote certificate list
for LDAP service.
in case LDAP server certificate has been signed by a CA, import the corresponding CA in the Certificate authorities
(CA) list for LDAP service.
Configure credentials to bind with the LDAP server or select anonymous if no credentials are required.
Configure the Search base DN .
Configure the request parameters (see examples below).
4.1.1.1.1 Typical request parameters
Parameter OpenLDAP Active Directory™ with POSIX
account activated
Active Directory™
User base DN ou=users, dc=example, dc=com ou=users, dc=example, dc=com ou=users, dc=example, dc=com
User name attribute uid uid sAMAccountName
UID attribute uidNumber uidNumber objectSid:S-1-5-xx-yy-zz (domain SID)
Group base DN ou=groups, dc=example, dc=com ou=groups, dc=example, dc=com ou=groups, dc=example, dc=com
Group name attribute gid gid sAMAccountName
GID attribute gidNumber gidNumber objectSid:S-1-5-xx-yy-zz (domain SID)
4.1.1.2 Testing connection to LDAP database
Refer to the sectionInformation>>>CLI>>>ldap-testto get help on the CLI command.
To test connection to the LDAP database:
Connect to the CLI.
Launch ldap-test --checkusername command.
In case of error, use the verbose option ofthe command to investigate the reason.
4.1.1.3 Map remote users to profile
This step is mandatory and configures the Network module to give permissions to the LDAP users.
Users not belonging to a group mapped on a profile will be rejected.
