Eaton Network-M2 - Modbus Communication Monitoring Tool; Example of Supported Modbus Mapping

Configuring Modbus
Installing the Network Management Module – 23
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Type: Register/Discrete
Size in bytes
Number of modbus registers
Writable: True/False
Representation: Int16/Uint16/String/Boolean/...
Name
Description
Unit (Kelvin, A, V, W, VA,%, Hz, min, ...)
Status to 0: status when the discrete equal 0
Status to 1:status when the discrete equal 1
Available: True/False –Shows if the register is available on current device
Value: Shows current value of the register on current device
2.5.3 Modbus communication monitoring tool
Access the CLI through SSH or the Serial terminal emulation
Get available commands by typing ? in the CLI
CLI commands can be used to retrieve Modbus communication statistics, seeInformation>>>CLI>>>modbus_statisticssectionfo
r more details.
2.5.4 Example of supported Modbus mapping
The following table is an example of the mapping information that can be retrieved in the Modbus settings by pressing the
Supported MAPs button.
For an example of supported Modbus mapping, navigate to Installing the Network Management
Module>>>Configuring Modbus>>>Example of supported Modbus mapping.
