Contextual help of the web interface – 36
•
•
Input measures Output measures
Voltage (V)
Current (A)
Frequency (Hz)
Voltage (V)
Current (A)
Frequency (Hz)
3.2.3.6.2 Example #2
Dual input sources with 3 phases in and 3 phases out
Input measures (main and secondary) Output measures
Phase #1
Voltage (V)
Current (A)
Phase #2
Voltage (V)
Current (A)
Phase #3
Voltage (V)
Current (A)
Phase #1
Voltage (V)
Current (A)
Phase #2
Voltage (V)
Current (A)
Phase #3
Voltage (V)
Current (A)
Load (W)
Load (%)
Frequency (Hz) Frequency (Hz)
3.2.4 Outlet status
Providesthe status of the UPS outlets (ON/OFF) by load segmentation:
Status (ON/OFF— Protected/Not protected/Not powered)
Load level (W)– availability depending on the UPS model
Note:To access Controls menu, press theicon:
3.2.5 Active Alarms
Only active alarms are displayed, the Alarmsicon will alsodisplay the number of active alarms.
Alarms are sorted by date,alert level, time, anddescription.
Note:To seethe alarm history,press the icon:
3.2.6 Environment
Sensor status and data are displayed if available,MIN-MAX shows the minimal and maximal temperature or humidity measured by
the sensor.
Note:To seedetailed sensor data,press theicon:
Note: Load segmentations allow non-priority equipment to automatically power down during an extended power
outage to keep battery runtime on essential equipment.
This feature is also used toremote reboot and sequential startservers to restrict inrush currents.
