Contextual help of the web interface – 35
•
•
•
•
•
•
•
•
•
•
Maintenance bypass
(optional)
Maintenance bypass closed. Maintenance
ATS device The equipment is powered
through an ATS device.
Description and
symbols
Description Possible states
Green Orange Black
Wiring Electrical connection between
blocks.
Energy flow In overload
Out of nominal range
No energy
Unknown
3.2.3.5 Details
To access the device details, press theicon:
Thisview provides a summary of device identification information and nominal values:
Name
Model
P/N
S/N
Location
Firmware version
Input Voltage
Input Frequency
Output Voltage
Output Frequency
TheCOPY TO CLIPBOARDbutton will copy the information toyour clipboard.
For example, you can copy and paste information into an email.
3.2.3.6 Show measures
Provides input and output measures on the synoptic.
3.2.3.6.1 Example #1
Single input source with 1 phase in and 1 phase out:
