7.5.3 9130 UPS(XCP) alarm log codes
7.5.3.1 Critical
Code Severity Active message Non-active message Advice
2012 Critical Emergency power OFF No emergency OFF -
2019 Critical Building alarm No building alarm -
2020 Critical Bypass temperature alarm Bypass temperature OK -
2024 Critical Temperature alarm Temperature OK -
2026 Critical Rectifier overload Rectifier OK -
2030 Critical Rectifier failure Rectifier OK -
2031 Critical Inverter internal failure UPS OK -
2034 Critical Battery charger fault Battery charger OK -
2056 Critical Battery low state of charge Battery state of charge OK -
2058 Critical Output short circuit Output OK -
2070 Critical UPS power supply fault UPS power supply OK -
2075 Critical Rectifier overload Rectifier OK -
2077 Critical Input AC module failure Input AC module OK -
2102 Critical Inverter limitation No current limitation -
2111 Critical Inverter thermal overload No power overload -
2112 Critical DCDC converter failure DCDC converter OK -
2132 Critical Parallel UPS protection lost Parallel UPS protection OK -
2143 Critical Maintenance bypass Not on maintenance bypass -
2188 Critical Bypass AC module failure Bypass AC module OK -
2191 Critical Battery fault Battery OK Check battery
2192 Critical Fuse fault Fuse OK -
2193 Critical Fan fault Fan OK -
2199 Critical No battery Battery present Check battery
2200 Critical Temperature out of range Temperature in range -
2259 Critical Rectifier short circuit Rectifier OK -
2260 Critical Rectifier short circuit Rectifier OK -
2261 Critical Rectifier short circuit Rectifier OK -
2323 Critical Inverter overload No power overload -
2324 Critical Inverter short circuit End of inverter short circuit -
Use this table for 9130 UPS.
To retrieve Alarm logs, navigate to Contextual help>>>Alarms section and press the Download alarms button.
Below codes are the one to be used to add "Exceptions on events notification" on email sending configurations.
Some zeros maybe added in front of the code when displayed in emails or logs.
