 Default settings and possible parameters
Information – 218
Default settings and possible parameters - Modbus
Default setting Possible parameters
Modbus RTU Enabled — Inactive
Baud rate (bps) — 19200
Parity — Even
Stop bits – 1
Enabled — Inactive/Active
Baud rate (bps) —
1200/2400/4800/9600/19200/38400/57600/1152
00
Parity — None/Even/Odd
Stop bits – 1/2
Modbus TCP Enabled — Inactive
Port — 502
Enabled — Inactive/Active
Port — x-xxx
Mapping configuration No mapping Name – 128 characters maximum
Map – Eaton ModbusMS compatible
Transport – RTU/TCP
Device ID – from 1 to 247
Access – None/Read only/Read/Write
Illegal read behaviour – Return exception/Return
zeros
Coil/register base address shift – No shift/Shift
by 1 (JBUS)
Default settings and possible parameters - Certificate
Default setting Possible parameters
Local certificates Common name — Service + Hostname + selfsigned
Country — FR
State or Province — 38
City or Locality — Grenoble
Organization name — Eaton
Organization unit — Power quality
Contact email address — blank
Common name — 64 characters maximum
Country — Country code
State or Province —64 characters maximum
City or Locality —64 characters maximum
Organization name —64 characters maximum
Organization unit —64 characters maximum
Contact email address —64 characters maximum
