SPECIFICATION
1 Power supply 6-20V, immunity to transients according to ISO
7637
2 Current requirement 400mA
3 Operating temperature -40 do 100˚ C
4 Supported number of cylinders 1-6 – full sequential injection and ignition
1-12 - wasted spark
5 Max supported RPM 12000
6 Injection time 0.1ms – 50ms, resolution 16us
7 Ignition timing 60˚ BTDC – 20˚ ATDC,resolution 0,5˚
8 Injectors outputs 6 protected outputs, max. current 5A
9 Ignition outputs 6 outputs, max. current 7A, software selectable
passive / active coils
10 AUX outputs 6 protected outputs, max. current 5A
11 AUX / Stepper 4 outputs,max. current 1A
12 Lambda sensors - narrow band 4 wires sensor,
- wide-band sensor Bosch LSU 4.2
13 Knock sensing 2channels, knock resonant frequency 1-20kHz
14 Crank / Cam signal (primary
trigger)
VR sensor (adaptive input), HALL / Optical, software
configurable
15 CAM sensors 2 inputs, VR or HALL / Optical software configurable
16 VSS VR or HALL / Optical software configurable
17 EGT 2 channels, K-Type thermocouples
18 Analog inputs 7 protected analog inputs for sensors TPS, IAT, CLT, etc.
19 Additional outputs Extension port: CANBus, Bluetooth, etc.
20 Other Built in 400 kPa MAP and Baro Sensor
21 Communication USB port
22 Client software Windows XP, VISTA, Windows 7
