I-2 System Requirements
- Existing cable/DSL modem & router
- Computer with web browser for access point configuration
I-3 Hardware Overview
A
12V DC IN
12V DC port to connect the power adapter
B
LAN 1 (PoE)
LAN port with Power over Ethernet (PoE) IN
C
LAN 2
LAN port
D
Reset
Reset the device to factory default settings
A
B
C
D
