Edimax CAP1300 - X-5-3-3 Add;Edit;Import;Export RADIUS Accounts

Edimax Pro NMS
194
certificate.
EAP Internal
Authentication
Select EAP internal authentication type from the drop down
menu.
Shared Secret
Enter a shared secret/password for use between the internal
RADIUS server and RADIUS client. The shared secret should
be 1 – 99 characters in length.
Session
Timeout
Set a duration of session timeout in seconds between 0 –
86400.
Termination
Action
Select a termination-action attribute: “Reauthentication”
sends a RADIUS request to the access point,
“Not-Reauthentication” sends a default termination-action
attribute to the access point, “Not-Send” no
termination-action attribute is sent to the access point.
X-5-3-3 Add/Edit/Import/Export RADIUS Accounts
The internal RADIUS server can authenticate up to 256 user accounts. The
“RADIUS Accounts” page allows you to configure and manage users.
