Edimax Pro NMS
142
4. Buzzer
The Managed AP’s buzzer will sound temporarily to help identify/locate
the access point.
5. Network Connectivity
Go to the “Network Connectivity” panel to perform a ping or traceroute.
6. Restart
Restarts the Managed AP.
Status Icons
Icon
Color
Status
Definition
Grey
Disconnected
Managed AP is disconnected. Please check
the network connection and ensure the
Managed AP is in the same IP subnet as the
AP Controller.
Red
Authentication
Failed
Or
Incompatible
NMS Version
System security must be the same for all
access points in the AP array. Please check
security settings (refer to X-5-13-1 System
Security).
All access points must have the same
firmware version. Please use the AP
Controller’s firmware upgrade function
(refer to X-5-12 Firmware Upgrade).
Orange
Configuring or
Upgrading
Please wait while the Managed AP makes
configurations or while the firmware is
upgrading.
Yellow
Connecting
Please wait while Managed AP is
connecting.
Green
Connected
Managed AP is connected.
Blue
Waiting for
Approval
Managed AP is waiting for approval. Note:
Up to sixteen Managed APs are supported.
Additional APs will have this status until an
existing Managed AP is removed.
