Edimax Pro NMS
259
5GHz WDS Mode
WDS
Functionality
Select “WDS with AP” to use WDS with access point or “WDS
Dedicated Mode” to use WDS and also block communication
with regular wireless clients. When WDS is used, each access
point should be configured with corresponding MAC
addresses, wireless channel and wireless encryption method.
Local MAC
Address
Displays the MAC address of your access point.
WDS Peer Settings
WDS #
Enter the MAC address for up to four other WDA devices you
wish to connect.
WDS VLAN
VLAN Mode
Specify the WDS VLAN mode to “Untagged Port” or “Tagged
Port”.
VLAN ID
Specify the WDS VLAN ID when “Untagged Port” is selected
above.
WDS Encryption
Encryption
Select whether to use “None” or “AES” encryption and enter a
pre-shared key for AES with 8-63 alphanumeric characters.
Press “Apply” to apply the configuration, or “Reset” to forfeit the changes.
