Edimax CAP1300 - Page 348

348
wlan 2.4g band
Set the operating mode of the radio and BasicRateSet on 802.11g, and configure the wireless channel.
<The syntax of the command>
wlan 2.4g band 11b brs { 2m | all } channel {ch} bandwidth 20m
wlan 2.4g band 11b brs { 2m | all } channel {auto-ch} bandwidth 20m
wlan 2.4g band { 11g | 11b11g} brs {brs} channel {ch} bandwidth 20m
wlan 2.4g band { 11g | 11b11g} brs {brs} channel {auto-ch} bandwidth 20m
wlan 2.4g band { 11g11n|11b11g11n} brs {brs} channel {ch} bandwidth {width}
wlan 2.4g band { 11g11n|11b11g11n} brs {brs} channel {auto-ch} bandwidth {autowidth}
- <Parameter>
{brs} Select from the following basic rate set
2m Set to 1/2 Mbps
11m Set to 1/2/5.5/11 Mbps
24m Set to 1/2/5.5/6/11/12/24Mbps
All Set all rate supported by current band
{ch} Set the wireless channel of 802.11g
Available channel number: 1-13
{autoch} Set the wireless auto channel of 802.11g
Available channel number: auto_1-11ch, auto_1-13ch
{width} Set the wireless bandwidth of 802.11g
20m Set to 20MHz normal mode
40m+ex_upper_ch Set to 40MHz normal mode plus extra upper channel
Available values: 1-9
40m+ex_lower_ch Set to 40MHz normal mode plus extra lower channel
Available values: 5-13
auto+ex_upper_ch Set to auto mode plus extra upper channel
Available values: 1-9
auto+ex_lower_ch Set to auto mode plus extra lower channel
Available values: 5-13
{autowidth}
20m Set to 20MHz normal mode
40m Set to 40MHz normal mode
auto Set to auto mode
- <Default configuration>
Mode: 11b11g11n
BasicRateSet: 11m
Channel: auto_1-11ch
Bandwidth: 20m
- <Command mode>
Immediate Mode, Edit Mode
- <Compatible Products>
CAP1300
- <Examples>
# wlan 2.4g band 11b brs 2m channel 6 bandwidth 20m
