AP, Managed AP, Repeater & Client Bridge Modes
89
RADIUS Type
Select “Internal” to use the access point’s built-in RADIUS
server or “external” to use an external RADIUS server.
RADIUS Server
Enter the RADIUS server host IP address.
Authentication
Port
Set the UDP port used in the authentication protocol of the
RADIUS server. Value must be between 1 – 65535.
Shared Secret
Enter a shared secret/password between 1 – 99 characters in
length. This should match the “MAC-RADIUS” password used
in VI-3-3-3 or VI-3-4-3.
Session
Timeout
Set a duration of session timeout in seconds between 0 –
86400.
Accounting
Enable or disable RADIUS accounting.
Accounting
Port
When accounting is enabled (above), set the UDP port used
in the accounting protocol of the RADIUS server. Value must
be between 1 – 65535.
Press “Apply” to apply the configuration, or “Cancel” to forfeit the changes.
