Programming (continued)
Examples:
• &S12,PWR,13,0<cr> turns Zone 13 off.
• &S12,PWR,02?<cr> queries Zone 2.
• &S12,PWR,13,1<cr> turns Zone 13 on.
• &S12,PWR,13,2<cr> toggles Zone 13 from on to
off or off to on.
SRC (Source)
Description:
• Selects a specified Source ss in a Zone zz.
• Automatically switches audio and video as pro
grammed in VIA!TOOLs.
• If the zone is off, zone will turn on with ss = 01-13.
Command:
&S12,SRC,zz,ss<cr>
Query:
&S12,SRC,zz?<cr>
Reply:
&S12,SRC,zz,ab<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
ss:
Source 01-13
00 is zone off
13 is local source
Examples:
• &S12,SRC,13,11<cr> selects Source 11 in Zone
13.
• &S12,SRC,02?<cr> queries Zone 2 for selected
source.
• &S12,SRC,09,00<cr> turns Zone 9 off
SYSOFF (System Off)
Description:
• Turns all zones off.
• Only Chassis 1 will respond.
Command:
&S12,SYSOFF<cr>
Query:
&S12,SYSOFF?<cr>
Reply:
&S12,SYSOFF,a<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
a:
0 = OFF
1 = ON
Examples:
• &S12,SYSOFF<cr> turns System off.
• &S12,SYSOFF?<cr> queries System status.
• &S12,SYSOFF,0<cr> S12 returns System is off.
TRE (Treble)
Description:
• Sets Zone zz to treble xyz.
• Increment Zone zz treble.
• Decrement Zone zz treble.
• Has no affect if zone is off.
• If sending 00, the + or - can be omitted.
Command:
&S12,TRE,zz,a<cr>
&S12,TRE,zz,xyz<cr>
Query:
&S12,TRE,zz?<cr>
Reply:
&S12,TRE,zz,xyz<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
a:
+ = Increments (plus symbol)
- = Decrements (minus symbol)
x:
+ Sets to positive number (plus symbol)
- Sets to negative number (minus symbol)
yz:
00 - 18
00 = Flat
Examples:
• &S12,TRE,+13,+<cr> Increments Zone 13's treble.
• &S12,TRE,02?<cr> queries Zone 2 for its treble.
• &S12,TRE,13,-03<cr> sets Zone 13's treble to -3
• &S12,TRE,13,00<cr> Zone 13 treble is flat.
