Gas valve - Natural gas and LPG
Pos. 1. Nozzle
Thenozzleorificesizemustbecorrectfortheinstallation
altitude(USonly)andthetypeofgasbeingused.
Seetheinstallationmanualtodetermineproperorificesize.
Pos. 2.Measuringtap,nozzlepressure
Measuringseelaterinthissection.
Pos. 3 + 4.Nozzlepressureadjustmentscrewandcap
Setthenozzlepressurebyusingadjustingscrew(4)found
behindcoverscrew(3).
Clockwise: higherpressure
Counter-clockwise:lowerpressure
Pos. 5.Controlbox,gasvalve
Pos. 6.Measuringtap,supplypressure
Measuringseelaterinthissection.
Supplypressureseeinstallationmanual.
Note!ThegassupplyMUSTbeturnedoffbeforeloosening
tappos.6(SUPPLY)orgaswillescape.
Pos. 7.Primaryairflowreducingplate.
