Inlet air - thermistor element (PT100 sensor)
Function
Thethermistorelementmeasuresthetemperatureoftheheatedairenteringthedrum.
Theresistanceofthisdeviceisnormally110kOhmsat20°C(68°F)andincreasesasthe
temperaturerises.
ThesignalisreturnedtothePCBandthisensuresthattheinletairdoesnotbecome
excessivelyhot,thuspreventingscorchingofgarments.
Replacement
Gas and electric heated dryers, fig. 1
TheelementAislocatedattheheatingunit.
Openthefrontshutter.ElementAcannowbereplacedbydismountingtheangleplate.
Error codes
Thefollowingerrorcodesarerelatedtothissection:
E03, E17
SeeSelectaControlServiceManualformoreinformation.
1
A
