Electrolux T4900 - Adjusting and Replacing Wire Ropes

91
Sliding Door
Service
manual
Adjusting the wire rope
Checkthatthewireistightened:
1.Loosenall6wireclampsA.
  2,5kgwiretractionmustresultinamotionof
100mmasshowninfigure1.
2. AdjustwithadjustingscrewJ.
3.PlacethewireinthewireclampsA andtighten
all6ofthem.
1
100 mm
J
A
A
A
A
A
A
