Replacements on fan module
Fig.1Itisnowpossibletochangethe
following:
•Motor (a)
•Fan wheel (b)
Dismounting fan wheel / motor
1.Fig.2.UnscrewscrewAwithwasher.
2.Fig.3.Pullthefanwheeloffthemotor
 shaftusingawheeldresser.
3.Fanwheelormotorcannowbere-
 placed.Becarefulnottodamagethe
 fanwheel.
Mounting motor
Ifamotorhasbeentakenapart/
replaceditisimportanttolubricatethe
motorshaftwithananti-frettingpaste
(AntifretLAGF3/0.6orsimilarquality).
1.Mountmotoronmotorbridgewith
 4screws.
2.Tightenthe4screwswith20Nm.
3. Fig.4.Mountfanwheel,lubricate
 screwAusingaprotectionproduct
 suchasOmnifitSeal40Morsimilar
 qualityandtightenwith5Nm.
4.Fanmodulecannowbemountedon
 thedryer.
5.Tightenthebelt,seesectionPeriodic
maintenance, Tightening belt.
Finishing replacement
1.Assemblethedryer.
2.Connectthepowersupplytothe
 dryer.
Function check
Checkthedryer,seesectionPeriodic
maintenance, Function check
a
A
b
B
5Nm
